YASKAWA MP2300S User Manual

2.3 Option Module
2.3.1 Option Module Overview List
2-63
Specifications and Functions
Input/Out-
put Module
LIO-01/
LIO-02
Module
Digital I/O and pulse counter functions.
As a digital I/O function, equipped with 16 digital inputs (DI), 16 digital
outputs (DO) (LIO-01: sink output, LIO-02: source output). As a pulse
counter function, one pulse input (PI). As for when to input/output for
digital I/O and pulse counter functions, input/output for each MP2200
high-speed (High)/ low-speed (Low) scan is carried out at a constant
cycle.
Machine Controller MP2300S
Basic Module User’s Manual
(manual number:
SIEP C880700 03)
LIO-04/
LIO-05
Module
As a digital I/O function, equipped with 32 digital inputs (DI), and 32
digital outputs (DO) (LIO-04: sink output, LIO-05: source output).
LIO-06
Module
As a digital I/O function, equipped with 8 digital inputs (DI), 8 digital
outputs (DO), one analog input channel, one analog output channel, and
one pulse counter input channel.
DO-01
Module
As a digital output function, equipped with 64 digital outputs (DO) (sink
output).
AI-01 Module
8 channel analogue input module. For the input, capable of selecting
from three options: -10V to +10V, 0V to +10V, or 0 to 20 mA.
Machine Controller MP2000
Series I/O Module User’s Manual
(manual number:
SIEP C880700 34)
AO-01
Module
4 channel analogue output module. For the output, select one from two
options: -10V to +10V, or 0V to +10V.
CNTR-01
Module
2 channel reversible counter module. 5 V differential/ 12 V input is
optional, and phase-A or -B/ sign/ add-subtract method is optional.
Machine Controller MP2000
Series Counter Module CNTR-01
User’s Manual (manual number:
SIEP C880700 27)
Communi-
cation
Module
218IF-01
Module
Equipped with serial interface (RS-232C) and Ethernet interface. Allows
you to connect to a personal computer, HMI equipment, or controller by
other makers via PORT or 10Base-T connector.
Machine Controller MP2000
Series Communication Module
User’s Manual (manual number:
SIEP C880700 04)
218IF-02
Module
Equipped with serial interface (RS-232C) and Ethernet interface. Allows
you to connect to a personal computer, HMI equipment, or controller by
other makers via PORT or 10Base-T connector.
217IF-01
Module
Equipped with serial interfaces (RS-232C and RS422/485). Allows you
to connect to a personal computer, HMI equipment, or controller by other
makers via PORT or RS422/485 connector.
260IF-01
Module
Equipped with serial interface (RS-232C) and DeviceNet interface.
Allows you to connect to a controller by other makers via DeviceNet
connector. Also, allows you to connect to a personal computer or HMI
equipment by other makers via the PORT connector.
261IF-01
Module
Equipped with serial interface (RS-232C) and PROFIBUS interface.
Allows you to connect to a controller by other makers via the PROFI-
BUS connector. Also, allows you to connect to a personal computer or
HMI equipment by other makers via the PORT connector.
215AIF-01
Module
MPLINK and CP-215 specifications.
MPLINK specification is equipped with one line of our original real-time
core network interface MPLINK transmissio
n and a serial interface
(RS-
232C).
CP-215 specification is equipped with one line of our original real-time
core network interface CP-215 transmission and a serial interface (RS-
232C).
262IF-01
Module
Equipped with an FL-net interface. Allows you to connect to a FA con-
troller, a personal computer, or HMI equipment via 100Base-TX/10Base-
T connector.
Machine Controller MP2000
Series 262IF-01 FL-net Commu-
nication Module User's Manual
(manual number:
SIEP C880700 36)
263IF-01
Module
Equipped with an EtherNet/IP interface. Allows you to connect a per-
sonal computer or equipment that supports EtherNet/IP communication
protocol.
Machine Controller MP2000
Series 263IF-01 EtherNet/IP
Communication Module User's
Manual (manual number:
SIEP C880700 39)
(cont’d)
Classification
Option
Module Name
Module Overview Reference Manual
