9-19

IM 05P02C41-01EN

Program Pattern Functions

• Operationwhenthemeasuredinputdoesnotattainthewaitzonewithinthewait

time

Ifthewaittimeelapsesbeforethemeasuredinputattainsthewaitzone,thewaitstate

is changed to the operating state and the program advances to the next segment the

moment that the wait time elapses. This happens even if the measured input has not

attainedthewaitzone.

Time

Wait time

Upper-side wait zone

Lower-side wait zone

Wait operation

Though PV has not attained the wait zone,

the program advances to the next segment

the moment that the wait time elapses.

TSP

If the wait time is OFF (No function), the controller keeps the wait status until PV has

attainedthewaitzone.

9.4SettingtheWaitFunctions
