18-10
IM 05P02C41-01EN
ProgramPatternSettingMenu(Menu:PROG>PTNO.(=01to30(99whentheoption
“/AP”isspecified))>SEGNO.(=01to99))
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
TSP
Final target
setpoint
EASY
0.0 to 100.0% of PV input range (EU)
(Setting range: P.RL to P.RH)
P.RL
TIME
Segment time
setting
EASY
-: Unregistered
0.00 to 999.59 (“hour.minute” or “minute.
second”)
* Setting available for the parameter
SEG.T=TIME.
* Use the parameter TMU to set
the time unit. (Common in the
instrument.)
* If the setting is 0.00, TSP changes in
stepwise after one control period.
-
TM.RT
Segment
ramp-rate
setting
EASY
-: Unregistered
Ramp: 0.0 to 100.0% of PV input range
span (EUS) / 1 hour or 1 minute
Soak: 0.00 to 999.59 (“hour.minute” or
“minute.second”)
* Setting available for the parameter
SEG.T=TM.RT.
* Use the parameter TMU to set
the time unit. (Common in the
instrument.)
Per 1 hour: TMU=HH.MM,
Per 1 minute: TMU=MM.SS
* If it is set to 0.0% of the input range
span, or the segment time 0.00, the
program moves to the next segment
after one control period.
-
S.PID
Segment
PID number
selection
EASY
1 to 8
* PID number can be set when the
parameter “ZON = 0.”
1
JC Junction code STD
CONT: Switching for continuation
HOLD: Hold-on switching (the controller
holds the end-of-segment setpoint when
the segment is completed, to perform
control).
LOC: Local-mode switching (the controller
switches to a local setpoint when the
segment is completed).
REM: Remote-mode switching (the
controller switches to a remote setpoint
when the segment is completed).
W.SW1 to W.SW5: Wait during switching
between segments.
W.IV1 to W.IV5: Wait within a segment
interval.
W.SL1 to W.SL5: Segment switching (the
controller switches to a local setpoint
when the segment is completed after
release.) (5 groups)
W.SR1 to W.SR5: Segment switching (the
controller switches to a remote setpoint
when the segment is completed after
release.) (5 groups)
PLK.1 to PLK.30 (PLK.99): Linked to
patterns 1 to 30 (99).
INS.: Allows a segment to be added to the
endofaspeciedsegment.
DEL.:Allowsaspeciedsegmenttobe
deleted.
CONT
When the program pattern-2 retransmission is selected (PT2.G=ON), the second loop is also
displayed for the parameter TSP. (LP2 lamp is lit.)
18.2ListofParameters
