YOKOGAWA UP55A User Manual

18-31
IM 05P02C41-01EN
Parameters
18
OutputSettingMenu(Menu:OUT)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
O1RS
Retransmission
output type of OUT
current output
STD Same as RTS OFF
O1RH
Maximum value
of retransmission
output scale of OUT
current output
STD
When O1RS = PV1, SP1, PV2,
SP2, TSP1, TSP2, PV, RSP, AIN2,
or AIN4,
O1RL + 1 digit to 30000
-19999 to O1RH - 1 digit
Decimal point position:
When O1RS=PV1, SP1, or TSP1,
decimal point position is same
as that of PV input.
When O1RS =PV2, SP2, or TSP2,
decimal point position is same
as that of RSP input.
When O1RS =PV, decimal point
position is same as that of PV
input scale.
When O1RS =RSP, decimal point
position is same as that of RSP
input scale.
When O1RS =AIN2, decimal point
position is same as that of AIN2
scale.
When O1RS =AIN4, decimal point
position is same as that of AIN4
scale.
-
O1RL
Minimum value
of retransmission
output scale of OUT
current output
STD -
O2RS
Retransmission
output type of OUT2
current output
STD Same as RTS OFF
O2RH
Maximum value
of retransmission
output scale of
OUT2 current
output
STD
When O2RS = PV1, SP1, PV2,
SP2, TSP1, TSP2, PV, RSP, AIN2,
or AIN4,
O2RL + 1 digit to 30000
-19999 to O2RH - 1 digit
Decimal point position:
When O2RS=PV1, SP1, or TSP1,
decimal point position is same
as that of PV input.
When O2RS =PV2, SP2, or TSP2,
decimal point position is same
as that of RSP input.
When O2RS =PV, decimal point
position is same as that of PV
input scale.
When O2RS =RSP, decimal point
position is same as that of RSP
input scale.
When O2RS =AIN2, decimal point
position is same as that of AIN2
scale.
When O2RS =AIN4, decimal point
position is same as that of AIN4
scale.
-
O2RL
Minimum value
of retransmission
output scale of
OUT2 current
output
STD -
18.2ListofParameters
