YOKOGAWA UP55A User Manual

18-30
IM 05P02C41-01EN
OutputSettingMenu(Menu:OUT)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
RTS
Retransmission
output type of RET
EASY
OFF: Disable
PV1: PV
SP1: SP
OUT1: OUT (Valve opening: 0 to
100 % in Position proportional
control)
LPS: 15 V DC loop power supply
PV2: Loop-2 PV
SP2: Loop-2 SP
OUT2: Loop-2 OUT
TSP1: Target SP
HOUT1: Heating-side OUT
COUT1: Cooling-side OUT
MV1: Position proportional output
internal computed value)
TSP2: Loop-2 target SP
HOUT2: Loop-2 heating-side OUT
COUT2: Loop-2 cooling-side OUT
MV2: Loop-2 position proportional
output (internal computed
value)
PV: PV terminals analog input
RSP: RSP terminals analog input
AIN2: AIN2 terminals analog input
AIN4: AIN4 terminals analog input
PV1
RTH
Maximum value
of retransmission
output scale of RET
STD
When RTS = PV1, SP1, PV2, SP2,
TSP1, TSP2, PV, RSP, AIN2, or
AIN4,
RTL + 1 digit to 30000
-19999 to RTH - 1 digit
Decimal point position:
When RTS=PV1, SP1, or TSP1,
decimal point position is same
as that of PV input.
When RTS=PV2, SP2, or TSP2,
decimal point position is same
as that of RSP input.
When RTS=PV, decimal point
position is same as that of PV
input scale.
When RTS=RSP, decimal point
position is same as that of RSP
input scale.
When RTS=AIN2, decimal point
position is same as that of AIN2
scale.
When RTS=AIN4, decimal point
position is same as that of AIN4
scale.
100 % of PV
input range
RTL
Minimum value
of retransmission
output scale of RET
STD
0 % of PV
input range
18.2ListofParameters
