EthernetCommunicationSettingMenu(Menu:ETHR)(E3terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
HSR
High-speed
response mode
EASY OFF, 1 to 8 1
BPS Baud rate EASY
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
38400
PRI Parity EASY
NONE: None
EVEN: Even
ODD: Odd
EVEN
IP1toIP4 IP address 1 to 4 EASY
0 to 255
Initial value: 192.168.1.1
See left
SM1toSM4 Subnet mask 1 to 4 EASY
0 to 255
Initial value: 255.255.255.0
See left
DG1toDG4
Default gateway 1
to 4
EASY
0 to 255
Initial value: 0.0.0.0
See left
PRT Port number EASY 502, 1024 to 65535 502
IPAR IP access restriction EASY OFF: Disable, ON: Enable OFF
1.IP1to
1.IP4
Permitted IP
address 1-1 to 1-4
EASY
0 to 255
Initial value: 255.255.255.255
See left
2.IP1to
2.IP4
Permitted IP
address 2-1 to 2-4
EASY
0 to 255
Initial value: 255.255.255.255
See left
ESW
Ethernet setting
switch
EASY
OFF, ON
Setting this parameter to
“ON” enables the Ethernet
communication parameter settings.
* The parameter ESW
automatically returns to “OFF”
after “ON” is set.
OFF
When each parameter is displayed, the terminal area (E3) is displayed on Group display.
PROFIBUS-DPCommunicationSettingMenu(Menu:PROF)(E3terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
BR Baud rate EASY
9.6K: 9.6k bps
19.2K: 19.2k bps
93.75K: 93.75k bps
187.5K: 187.5k bps
0.5M: 0.5M bps
1.5M: 1.5M bps
3M: 3M bps
6M: 6M bps
12M: 12M bps
AUTO
45.45K: 45.45k bps
AUTO
ADR Address EASY 0 to 125 3
BPS Baud rate EASY
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
38400
FILE Prolenumber EASY 0, 11 to 15 0
SCAN
Automatic rescan
time
PRO
OFF
1M: 1 minute
10M: 10 minutes
30M: 30 minutes
60M: 60 minutes
OFF
When each parameter is displayed, the terminal area (E3) is displayed on Group display.
