YOKOGAWA UP55A User Manual

18-35
IM 05P02C41-01EN
Parameters
18
DeviceNetCommunicationSettingMenu(Menu:DNET)(E3terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
BR Baud rate EASY
125K: 125k bps
250K: 250k bps
500K: 500k bps
125K
ADR Address EASY 0 to 63 63
BPS Baud rate EASY
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
38400
FILE Prolenumber EASY 0, 11 to 15 0
SCAN
Automatic rescan
time
PRO
OFF
1M: 1 minute
10M: 10 minutes
30M: 30 minutes
60M: 60 minutes
OFF
When each parameter is displayed, the terminal area (E3) is displayed on Group display.
CC-LinkCommunicationSettingMenu(Menu:CC-L)(E3terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
BR Baud rate EASY
156K: 156k bps
625K: 625k bps
2.5M: 2.5M bps
5M: 5M bps
10M: 10M bps
10M
ADR Address EASY 1 to 64 1
BPS Baud rate EASY
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
38400
FILE Prolenumber EASY
0, 11 to 15
(0, 11: Ver.1.10) (12 to 15:
Ver.2.00)
0
SCAN
Automatic rescan
time
PRO
OFF
1M: 1 minute
10M: 10 minutes
30M: 30 minutes
60M: 60 minutes
OFF
When each parameter is displayed, the terminal area (E3) is displayed on Group display.
18.2ListofParameters
