KeyActionSettingMenu(Menu:KEY)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
RUN
RUN key action
setting
PRO
OFF: Disable
PROG: Switch to PROG (Start of
program operation)
RESET: Switch to RESET (Stop of
program operation)
LOCAL: Switch to LOCAL(LSP)
(Start of local-mode operation)
REM: Switch to REMOTE
P/R: PROG/RESET Switch
P/H: PROG/HOLD Switch
P/L: PROG/LOCAL(LSP) Switch
L/C: LOCAL(LSP)/CAS switch
HLD: Switch to HOLD (Start of
hold-mode operation)
ADV: Advance of segment
A/M1: Loop-1 AUTO/MAN switch
A/M2: Loop-2 AUTO/MAN switch
PRG1: Switch to PROG1 (Start of
program-1 operation)
PRG2: Switch to PROG2 (Start of
program-2 operation)
AT: Auto-tuning
LTUP: LCD brightness UP
LTDN: LCD brightness DOWN
BRI:AdjustLCDbrightness
LCD: LCD backlight ON/OFF
switch
LAT: Latch release
PID: PID tuning switch
PTN: Program pattern number
switch
MODE: Operation mode
PROG
RST
RST key action
setting
PRO RESET
PTN
PTN key action
setting
PRO PTN
MODE
MODE key action
setting
PRO MODE
18.2ListofParameters
