18-45
IM 05P02C41-01EN
Parameters
18
DIFunctionRegistrationMenu(Menu:DI.SL)
Parameter
symbol
Name
Display
level
Settingrange Initialvalue
PRG
Switch to PROG (Start of
program operation)
STD
Set an I relay number of
contact input.
Set “OFF” to disable the
function.
Standard terminals
DI1: 5025, DI2: 5026,
DI3: 5027
E1-terminal area
DI11: 5041, DI12: 5042,
DI13: 5043, DI14: 5044,
DI15: 5045, DI16: 5046
E2-terminal area
DI21: 5057, DI22: 5058,
DI23: 5059, DI24: 5060,
DI25: 5061, DI26: 5062
E3-terminal area
DI31: 5073, DI32: 5074,
DI33: 5075, DI34: 5076,
DI35: 5077
E4-terminal area
DI41: 5089, DI42: 5090,
DI43: 5091, DI44: 5092,
DI45: 5093, DI46: 5094
5025
RST
Switch to RESET (Stop
of program operation)
STD 5026
LOC
Switch to LOCAL(LSP)
(Start of local-mode
operation)
STD 5027
REM Switch to REMOTE STD 5046
P/R PROG/RESET Switch STD OFF
P/H PROG/HOLD Switch STD OFF
P/L
PROG/LOCAL(LSP)
Switch
STD OFF
HOLD
Switch to HOLD (Start of
hold-mode operation)
STD OFF
ADV Advance of segment STD OFF
WAIT Wait ON/OFF switch STD OFF
S.HLD
Switch to HOLD for
synchronizedprogram
operation
PRO OFF
A/M AUTO/MAN switch STD OFF
L/C LOCAL(LSP)/CAS switch STD OFF
AT
Auto-tuning START/
STOP switch
STD OFF
TRK Output tracking switch PRO OFF
SW PV switch PRO OFF
LAT Latch release STD OFF
LCD
LCD backlight ON/OFF
switch
STD OFF
PVRW PV red/white switch STD OFF
MG1
Message display
interruption 1
PRO OFF
MG2
Message display
interruption 2
PRO OFF
MG3
Message display
interruption 3
PRO OFF
MG4
Message display
interruption 4
PRO OFF
In Cascade control, the following parameters are also displayed for secondary loop. (the LP2 lamp
is lit)
• Parameter: A/M, PVRW
18.2ListofParameters
