Power ON Circuitry
Page 4 - 23
Electrical
Troubleshooting Guide
IRB6400 M94A
Figure 4-1 Inside Front of Control Cabinet
4.6 Component Location Figures
PT
SYSTEM
BOARD
POWER SUPPLY
TM1
TM1.XT1
EV5
FS1
FU1-3
XT31
