Page 7 - 9
Power Unit Circuitry
Electrical
Troubleshooting Guide
IRB6400 M94A
Component Component Circuit Location
Name Location Diagram Figure
Number
7.6 Component Cross Reference
Power unit Swing gate, top Sheet 9 7-1
KM1 Power unit Sheet 9 7-1
KM2 Power unit Sheet 9 7-1
KM3 Power unit Sheet 9 7-1
KM4 Power unit Sheet 9 7-1
System board AP41 Swing gate, front sheet 8 7-2
XS3/XT3 Cabinet, back Sheet 8 7-2
Drive system AP1 Swing gate, upper Sheet 12 7-3
