Page 5 - 33
Motors ON/Dual Run Chain Circuitry
Electrical
Troubleshooting Guide
IRB6400 M94A
Figure 5-3 System Board K1CR & K2CR
256A
K1CR & K2CR
SYSTEM
BOARD
