Parts Lists
Appendix B - 3
Electrical
Troubleshooting Guide
IRB6400 M94A
B. PARTS LISTS
B1. Control System Parts List
B1.1 Power Supply Side
Item Qty. Name Art. No. Rem
Z1 Power supply filter 3HAB 5425-1
QS1 Lockable circuit breaker 5324 688-3
Automatic fuse 3HAB 2017-2 Option 143/144
Flange disconnector 3HAB 2703-1 400-475V
3HAB 2703-2 400-600V
TM1 Transformer with automatic fuse
and 5x20mm fuses
3HAB 2947-1 200-400V
3HAB 2945-1 400-500V
3HAB 2946-1 475-600V
FS1 1 Automatic fuse 3HAB 5107-1 4-pole
2 Fuse 5672 817-22 6, 3A slow, 5x20mm
1 Fuse 5672 817-19 3.15A
B1.2 Operator's Panel
Item Qty. Name Art. No. Rem
SA1 1 Operating mode selector 3HAA 3003-21
SA2,3 2 Lamp pushbutton SK 615 202-CH
3 Contact block SK 616 001-A
2 Lamp block SK 616 003-A
2 Glow lamp 5911 069-10 36V 3,5 W, BA 9S
SA4 1 EM stop button 3HAB 5171-1
1 Contact block 3HAB 5171-10
D1 Floppy disk unit 3HAB 2596-1 Contains the floppy
Floppy disk driver 3HAB 2480-1 disk driver
Cable 3HAB 2759-1
PT Duty time counter 3HAA 3001-7 24V DC
