Table 46: ZMFPDIS Non group settings (advanced)
Name Values (Range) Unit Step Default Description
ZZeroDb 0 - 100000 m% 100 0 Zero point clamping
ZHiHiLim 0.0 - 5000.0 Ohm 0.1 800.0 High High limit in ohm
ZHiLim 0.0 - 5000.0 Ohm 0.1 150.0 High limit in ohm
ZLowLim 0.0 - 5000.0 Ohm 0.1 50.0 Low limit in ohm
ZLowLowLim 0.0 - 5000.0 Ohm 0.1 35.0 Low Low limit in ohm
ZMin 0.000 - 5000.000 Ohm 0.001 0.005 Minimum value in ohm
ZLimHys 0.000 - 100.000 % 0.001 0.500 Hysteresis value in % of range and is
common for all limits
7.1.6 Monitored data
PID-7066-MONITOREDDATA v1
Table 47: ZMFPDIS Monitored data
Name Type Values (Range) Unit Description
L1Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in phase L1
L2Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in phase L2
L3Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in phase L3
L1L2Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in loop L1L2
L2L3Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in loop L2L3
L3L1Dir INTEGER 1=Forward
2=Reverse
0=No direction
-
Direction in loop L3L1
L1R REAL - Ohm Resistance in phase L1
L1X REAL - Ohm Reactance in phase L1
L2R REAL - Ohm Resistance in phase L2
L2X REAL - Ohm Reactance in phase L2
L3R REAL - Ohm Resistance in phase L3
L3X REAL - Ohm Reactance in phase L3
L12R REAL - Ohm Resistance in phase L1-
L2
L12X REAL - Ohm Reactance in phase L1-
L2
L23R REAL - Ohm Resistance in phase L2-
L3
Table continues on next page
