Name Type Description
HMICTR4 INTEGER Bitmask output 4 to local remote LHMI input
HMICTR5 INTEGER Bitmask output 5 to local remote LHMI input
HMICTR6 INTEGER Bitmask output 6 to local remote LHMI input
HMICTR7 INTEGER Bitmask output 7 to local remote LHMI input
HMICTR8 INTEGER Bitmask output 8 to local remote LHMI input
HMICTR9 INTEGER Bitmask output 9 to local remote LHMI input
HMICTR10 INTEGER Bitmask output 10 to local remote LHMI input
HMICTR11 INTEGER Bitmask output 11 to local remote LHMI input
HMICTR12 INTEGER Bitmask output 12 to local remote LHMI input
12.4.5.3 Settings
PID-3944-SETTINGS v7
Table 194: LOCREM Non group settings (basic)
Name Values (Range) Unit Step Default Description
ControlMode Internal LR-switch
External LR-switch
- - Internal LR-switch Control mode for internal/external LR-
switch
PID-3943-SETTINGS v2
12.4.5.4 Operation principle
M17087-3 v8
The function block Local remote (LOCREM) handles the signals coming from the
local/remote switch. The connections are seen in Figure 169, where the inputs on
function block LOCREM are connected to binary inputs if an external switch is
used. When the local HMI is used, the inputs are not used. The switching between
external and local HMI source is done through the parameter ControlMode. The
outputs from the LOCREM function block control the output PSTO (Permitted
Source To Operate) on Bay control (QCBAY).
1MRK 505 394-UEN A Section 12
Control
Line differential protection RED650 2.2 IEC 359
Technical manual
