14.11.4 Signals
PID-6944-INPUTSIGNALS v2
Table 316: BTIGAPC Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
IN1 BOOLEAN 0 Input 1
IN2 BOOLEAN 0 Input 2
IN3 BOOLEAN 0 Input 3
IN4 BOOLEAN 0 Input 4
IN5 BOOLEAN 0 Input 5
IN6 BOOLEAN 0 Input 6
IN7 BOOLEAN 0 Input 7
IN8 BOOLEAN 0 Input 8
IN9 BOOLEAN 0 Input 9
IN10 BOOLEAN 0 Input 10
IN11 BOOLEAN 0 Input 11
IN12 BOOLEAN 0 Input 12
IN13 BOOLEAN 0 Input 13
IN14 BOOLEAN 0 Input 14
IN15 BOOLEAN 0 Input 15
IN16 BOOLEAN 0 Input 16
PID-6944-OUTPUTSIGNALS v2
Table 317: BTIGAPC Output signals
Name
Type Description
OUT INTEGER Output value
14.11.5 Settings
ABBD8E283673 v3
The function does not have any parameters available in the local HMI or PCM600.
14.11.6 Monitored data
PID-6944-MONITOREDDATA v2
Table 318: BTIGAPC Monitored data
Name
Type Values (Range) Unit Description
OUT INTEGER - - Output value
