Name Values (Range) Unit Step Default Description
UL3HiLim 0.0 - 200.0 %UB 0.1 120.0 High limit in % of UBase
UL3LowLim 0.0 - 200.0 %UB 0.1 80.0 Low limit in % of UBase
UL3LowLowLim 0.0 - 200.0 %UB 0.1 60.0 Low Low limit in % of UBase
15.1.6 Monitored data
PID-6713-MONITOREDDATA v3
Table 365: CVMMXN Monitored data
Name Type Values (Range) Unit Description
S REAL - MVA Apparent Power
magnitude of deadband
value
P
REAL - MW Active Power magnitude
of deadband value
Q REAL - MVAr Reactive Power
magnitude of deadband
value
PF
REAL - - Power Factor magnitude
of deadband value
U REAL - kV Calculated voltage
magnitude of deadband
value
I
REAL - A Calculated current
magnitude of deadband
value
F
REAL - Hz System frequency
magnitude of deadband
value
PID-6735-MONITOREDDATA v3
Table 366: CMMXU Monitored data
Name
Type Values (Range) Unit Description
IL1 REAL - A IL1 Amplitude,
magnitude of reported
value
IL1ANGL
REAL - deg IL1 Angle, magnitude of
reported value
IL2 REAL - A IL2 Amplitude,
magnitude of reported
value
IL2ANGL
REAL - deg IL2 Angle, magnitude of
reported value
IL3 REAL - A IL3 Amplitude,
magnitude of reported
value
IL3ANGL
REAL - deg IL3 Angle, magnitude of
reported value
Section 15 1MRK 505 394-UEN A
Monitoring
516 Line differential protection RED650 2.2 IEC
Technical manual
