PID-1657-OUTPUTSIGNALS v19
Table 29: FNKEYMD1 Output signals
Name Type Description
FKEYOUT1 BOOLEAN Output controlled by function key
5.4.4 Settings
PID-1657-SETTINGS v19
Table 30: FNKEYMD1 Non group settings (basic)
Name Values (Range) Unit Step Default Description
Mode Off
Toggle
Pulsed
-
- Off Output operation mode
PulseTime 0.001 - 60.000 s 0.001 0.200 Pulse time for output controlled by
LCDFn1
LabelOn 0 - 18 - 1 LCD_FN1_ON Label for LED on state
LabelOff 0 - 18 - 1 LCD_FN1_OFF Label for LED off state
PID-6452-SETTINGS v2
Table 31: FNKEYTY1 Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Type Off
Menu shortcut
Control
-
- Off Function key type
MenuShortcut - 0 Menu shortcut for function key
GUID-BCE87D54-C836-40EE-8DA7-779B767059AB v1
MenuShortcut values are product dependent and created dynamically depending on
the product main menu.
