15.9.8 Technical data
M14987-1 v6
Table 418: LMBRFLO technical data
Function
Value or range Accuracy
Reactive and resistive reach (0.001-1500.000) Ω/phase ±2.0% static accuracy
Conditions:
Voltage range: (0.1-1.1) x U
r
Current range: (0.5-30) x I
r
Phase selection
According to input signals -
Maximum number of fault
locations
100 -
15.10 Limit counter L4UFCNT
GUID-22E141DB-38B3-462C-B031-73F7466DD135 v1
15.10.1 Identification
15.10.1.1 Identification
GUID-F3FB7B33-B189-4819-A1F0-8AC7762E9B7E v2
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Limit counter L4UFCNT -
15.10.2 Functionality
GUID-13157EAB-1686-4D2E-85DF-EC89768F3572 v6
The Limit counter (L4UFCNT) provides a settable counter with four independent
limits where the number of positive and/or negative flanks on the input signal are
counted against the setting values for limits. The output for each limit is activated
when the counted value reaches that limit.
Overflow indication is included for each up-counter.
15.10.3 Operation principle
GUID-4D58423F-329C-4553-9FAF-E55A368849A5 v2
Limit counter (L4UFCNT) counts the number of positive and/or negative flanks on
the binary input signal depending on the function settings. L4UFCNT also checks
if the accumulated value is equal or greater than any of its four settable limits. The
four limit outputs will be activated relatively on reach of each limit and remain
activated until the reset of the function. Moreover, the content of L4UFCNT is
stored in flash memory and will not be lost at an auxiliary power interruption.
1MRK 505 394-UEN A Section 15
Monitoring
Line differential protection RED650 2.2 IEC 599
Technical manual
