PID-3992-OUTPUTSIGNALS v6
Table 22: LHMICTRL Output signals
Name Type Description
HMI-ON BOOLEAN Backlight of the LCD display is active
RED-S BOOLEAN Red LED on the LCD-HMI is steady
YELLOW-S BOOLEAN Yellow LED on the LCD-HMI is steady
YELLOW-F BOOLEAN Yellow LED on the LCD-HMI is flashing
CLRPULSE BOOLEAN A pulse is provided when the LEDs on the LCD-
HMI are cleared
LEDSCLRD BOOLEAN Active when the LEDs on the LCD-HMI are not
active
5.3 Basic part for LED indication module
5.3.1 Identification
GUID-6E36C0BC-F284-4C88-A4A8-9535D3BE8B14 v2
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Basic part for LED indication module LEDGEN - -
Basic part for LED indication HW
module
GRP1_LED1 -
GRP1_LED15
GRP2_LED1 -
GRP2_LED15
GRP3_LED1 -
GRP3_LED15
- -
5.3.2 Function block
GUID-BDB5797F-F27E-4FEE-9FDB-1C9E2F572BB6 v3
LEDGEN
BLOCK
RESET
NEWIND
ACK
IEC09000321-1-en.vsd
IEC09000321 V1 EN-US
Figure 4: LEDGEN function block
GRP1_LED1
^HM1L01R
^HM1L01Y
^HM1L01G
IEC09000322 V1 EN-US
Figure 5: GRP1_LED1 function block
The GRP1_LED1 function block is an example. The 15 LEDs in each of the three
groups have a similar function block.
