18.8.7.5 Settings
PID-3975-SETTINGS v5
Table 511: I103IED Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
18.8.8 Supervison status for IEC 60870-5-103 I103SUPERV
18.8.8.1 Functionality
GUID-E7A28D8D-398E-437C-9B58-AE125BC38058 v1
I103SUPERV is a function block with defined functions for supervision indications
in monitor direction. This block includes the FunctionType parameter, and the
information number parameter is defined for each output signal.
18.8.8.2 Identification
GUID-C8113B08-3586-412C-A750-606159B1E97E v1
Function description Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
Supervison status for IEC 60870-5-103 I103SUPERV - -
18.8.8.3 Function block
GUID-69C2C974-2D64-4174-9F9A-15383C09050D v1
IEC10000293-1-en.vsd
I103SUPERV
BLOCK
32_MEASI
33_MEASU
37_IBKUP
38_VTFF
46_GRWA
47_GRAL
IEC10000293 V1 EN-US
Figure 343: I103SUPERV function block
18.8.8.4 Signals
PID-3976-INPUTSIGNALS v5
Table 512: I103SUPERV Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of status reporting
32_MEASI BOOLEAN 0 Information number 32, measurand supervision of
I
33_MEASU BOOLEAN 0 Information number 33, measurand supervision of
U
Table continues on next page
Section 18 1MRK 505 394-UEN A
Station communication
716 Line differential protection RED650 2.2 IEC
Technical manual
