15.6.4 Signals
PID-3949-OUTPUTSIGNALS v2
Table 395: DRPRDRE Output signals
Name
Type Description
DRPOFF BOOLEAN Disturbance report function turned off
RECSTART BOOLEAN Disturbance recording started
RECMADE BOOLEAN Disturbance recording made
CLEARED BOOLEAN All disturbances in the disturbance report cleared
MEMUSED BOOLEAN More than 80% of memory used
PID-4014-INPUTSIGNALS v6
Table 396: A1RADR Input signals
Name Type Default Description
GRPINPUT1 GROUP
SIGNAL
- Group signal for input 1
GRPINPUT2 GROUP
SIGNAL
- Group signal for input 2
GRPINPUT3 GROUP
SIGNAL
- Group signal for input 3
GRPINPUT4 GROUP
SIGNAL
- Group signal for input 4
GRPINPUT5 GROUP
SIGNAL
- Group signal for input 5
GRPINPUT6 GROUP
SIGNAL
- Group signal for input 6
GRPINPUT7 GROUP
SIGNAL
- Group signal for input 7
GRPINPUT8 GROUP
SIGNAL
- Group signal for input 8
GRPINPUT9 GROUP
SIGNAL
- Group signal for input 9
GRPINPUT10 GROUP
SIGNAL
- Group signal for input 10
GUID-D025D5D9-A0F3-4A00-891A-63AD5F609A77 v2
A2RADR and A3RADR functions have the same input signal specifications as
A1RADR but with different numbering:
• A2RADR: GRPINPUT11 to GRPINPUT20 (group signal for inputs 11 to 20)
• A3RADR: GRPINPUT21 to GRPINPUT30 (group signal for inputs 21 to 30)
A4RADR block is used to record the calculated analog values of any type, not
related to hardware devices (e.g. difference currents, power factors etc.).
