Name Type Default Description
37_IBKUP BOOLEAN 0 Information number 37, I high-high back-up
protection
38_VTFF BOOLEAN 0 Information number 38, fuse failure VT
46_GRWA BOOLEAN 0 Information number 46, group warning
47_GRAL BOOLEAN 0 Information number 47, group alarm
18.8.8.5 Settings
PID-3976-SETTINGS v5
Table 513: I103SUPERV Non group settings (basic)
Name Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
18.8.9 Status for user defined signals for IEC 60870-5-103
I103USRDEF
18.8.9.1 Functionality
GUID-DADC9CE4-2E80-426C-A3B6-A8E8C7AC3CD4 v3
I103USRDEF is a function block with user defined input signals in monitor
direction. Each instance is associated with a Function Type (FUN) and each input
signal with an Information Number (INF). Additionally, all input signals may be
defined to use relative time and how to respond to a GI request.
The user is responsible for assigning a proper FUN value and proper INF values to
all connected inputs. See Settings for details.
18.8.9.2 Identification
GUID-474FDF39-CEFC-4370-9393-13BE62159969 v2
Function description
Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
Status for user defined signals for IEC
60870-5-103
I103USRDEF - -
1MRK 505 394-UEN A Section 18
Station communication
Line differential protection RED650 2.2 IEC 717
Technical manual
