18.8.12.2 Identification
GUID-9D6D1636-36C6-4C4E-B157-2D827820DDC7 v1
Function description Function block
name
IEC 60617
identification
ANSI/IEEE C37.2
device number
Function commands user defined for
IEC 60870-5-103
I103USRCMD - -
18.8.12.3 Function block
GUID-5EBEAED5-ABD9-4257-B879-DF7FD9F7805A v1
IEC10000284-1-en.vsd
I103USRCMD
BLOCK ^OUTPUT1
^OUTPUT2
^OUTPUT3
^OUTPUT4
^OUTPUT5
^OUTPUT6
^OUTPUT7
^OUTPUT8
IEC10000284 V1 EN-US
Figure 347: I103USRCMD function block
18.8.12.4 Signals
PID-3790-INPUTSIGNALS v5
Table 522: I103USRCMD Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of commands
PID-3790-OUTPUTSIGNALS v5
Table 523: I103USRCMD Output signals
Name
Type Description
OUTPUT1 BOOLEAN Command output 1
OUTPUT2 BOOLEAN Command output 2
OUTPUT3 BOOLEAN Command output 3
OUTPUT4 BOOLEAN Command output 4
OUTPUT5 BOOLEAN Command output 5
OUTPUT6 BOOLEAN Command output 6
OUTPUT7 BOOLEAN Command output 7
OUTPUT8 BOOLEAN Command output 8
1MRK 505 394-UEN A Section 18
Station communication
Line differential protection RED650 2.2 IEC 723
Technical manual
