12.8.4 Signals
PID-3575-INPUTSIGNALS v8
Table 215: SPC8GAPC Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Blocks the function operation
PSTO INTEGER 1 Operator place selection
PID-3575-OUTPUTSIGNALS v8
Table 216: SPC8GAPC Output signals
Name Type Description
OUT1 BOOLEAN Command output 1
OUT2 BOOLEAN Command output 2
OUT3 BOOLEAN Command output 3
OUT4 BOOLEAN Command output 4
OUT5 BOOLEAN Command output 5
OUT6 BOOLEAN Command output 6
OUT7 BOOLEAN Command output 7
OUT8 BOOLEAN Command output 8
12.8.5 Settings
PID-3575-SETTINGS v8
Table 217: SPC8GAPC Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
PulseMode1 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for
output 1
tPulse1 0.01 - 6000.00 s 0.01 0.10 Pulse time output 1
PulseMode2 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for
output 2
tPulse2 0.01 - 6000.00 s 0.01 0.10 Pulse time output 2
PulseMode3 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for
output 3
tPulse3 0.01 - 6000.00 s 0.01 0.10 Pulse time output 3
PulseMode4 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for
output 4
tPulse4 0.01 - 6000.00 s 0.01 0.10 Pulse time output 4
PulseMode5 Pulsed
Latched
- - Pulsed Setting for pulsed/latched mode for
output 5
tPulse5 0.01 - 6000.00 s 0.01 0.10 Pulse time output 5
Table continues on next page
1MRK 505 394-UEN A Section 12
Control
Line differential protection RED650 2.2 IEC 393
Technical manual
