ABB RED650 - Functionality; Function Block; Signals

12.6.2 Functionality
SEMOD158756-5 v9
The Selector mini switch (VSGAPC) function block is a multipurpose function
used for a variety of applications, as a general purpose switch.
VSGAPC can be controlled from the menu, from a symbol on the single line
diagram (SLD) on the local HMI or from Binary inputs
12.6.3 Function block
SEMOD158768-4 v3
VSGAPC
BLOCK
PSTO
IPOS1
IPOS2
BLOCKED
POSITION
POS1
POS2
CMDPOS12
CMDPOS21
IEC14000066-1-en.vsd
IEC14000066 V1 EN-US
Figure 187: VSGAPC function block
12.6.4 Signals
PID-6504-INPUTSIGNALS v6
Table 209: VSGAPC Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 0 Operator place selection
IPOS1 BOOLEAN 0 Position 1 indicating input
IPOS2 BOOLEAN 0 Position 2 indicating input
PID-6504-OUTPUTSIGNALS v6
Table 210: VSGAPC Output signals
Name
Type Description
BLOCKED BOOLEAN The function is active but the functionality is
blocked
POSITION INTEGER Position indication, integer
POS1 BOOLEAN Position 1 indication, logical signal
POS2 BOOLEAN Position 2 indication, logical signal
CMDPOS12 BOOLEAN Execute command from position 1 to position 2
CMDPOS21 BOOLEAN Execute command from position 2 to position 1
