17.4.2 Settings
PID-6770-SETTINGS v2
Table 448: MU1 Non group settings (basic)
Name
Values (Range) Unit Step Default Description
SampleValueID 0 - 34 - 1 ABB_MU0101 Sample Value ID (SVID) for the merging
unit [0-34 char]
APConnection None
AP1
AP2
AP3
AP4
-
- None Access point connection for the merging
unit
PID-6850-SETTINGS v3
Table 449: MU1_HW Non group settings (basic)
Name Values (Range) Unit Step Default Description
CTStarPoint1 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTStarPoint2 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTStarPoint3 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
CTStarPoint4 FromObject
ToObject
- - ToObject ToObject= towards protected object,
FromObject= the opposite
17.4.3 Monitored data
PID-6850-MONITOREDDATA v3
Table 450: MU1_HW Monitored data
Name
Type Values (Range) Unit Description
MUDATA BOOLEAN 0=Ok
1=Error
- Fatal error, data not
received, transmission
errors, time-sync issues
or inconsistent sample
rate
SYNCH
BOOLEAN 0=Ok
1=Error
- High when IED clock is
not within configured
accuracy or time domain
SMPLLOST
BOOLEAN 1=Yes
0=No
- Fatal error or recovery
state after fatal error.
High if any subscribed
channel has bad quality
or TEST while IED not in
test mode.
MUSYNCH
BOOLEAN 0=Ok
1=Error
- MU not synced or MU
clock not synced to
same clock as IED
TESTMODE
BOOLEAN 1=Yes
0=No
- Quality of one or more
subscribed analogue
channels is TEST
Table continues on next page
1MRK 505 394-UEN A Section 17
Ethernet
Line differential protection RED650 2.2 IEC 631
Technical manual
