• the pulse length
• the number of pulses, that is, the number of rising and falling flank pairs
In principle, more pulses may lead to reduced accuracy.
15.11.6.2 Memory storage
GUID-B49698FF-0AB2-4792-A7CB-5534313B6CA0 v2
The value of the accumulated time is retained in a non-volatile memory,
• at every falling edge of the input IN
• at every even 6 minutes, after a rising edge of the input IN
• after a manual addition of time
Consequently in case of a power failure, there is a risk of losing the difference in
time between actual time and last time stored in the non-volatile memory.
15.11.7 Technical data
GUID-F5E124E3-0B85-41AC-9830-A2362FD289F2 v1
Table 427: TEILGAPC Technical data
Function
Range or value Accuracy
Time limit for alarm
supervision, tAlarm
(0 - 99999.9) hours ±0.1% of set value
Time limit for warning
supervision, tWarning
(0 - 99999.9) hours ±0.1% of set value
Time limit for overflow
supervision
Fixed to 99999.9 hours ±0.1%
1MRK 505 394-UEN A Section 15
Monitoring
Line differential protection RED650 2.2 IEC 607
Technical manual
