ABB RED650 User Manual

PID-6828-INPUTSIGNALS v3
Table 464: GOOSEDPRCV Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of function
SRCDPOUT INTEGER 0 Source to double point output
PID-6828-OUTPUTSIGNALS v3
Table 465: GOOSEDPRCV Output signals
Name Type Description
DPOUT INTEGER Double point output
DATAVALID BOOLEAN Data valid for double point output
COMMVALID BOOLEAN Communication valid for double point output
TEST BOOLEAN Test output
18.4.7.5 Settings
PID-6828-SETTINGS v3
Table 466: GOOSEDPRCV Non group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off/On
18.4.7.6 Operation principle
GUID-82A1C8A2-827A-40EF-8E58-F573E29E468E v4
The DATAVALID output will be HIGH if the incoming message is with valid data.
The COMMVALID output will become LOW when the sending IED is under total
failure condition and the GOOSE transmission from the sending IED does not
happen.
The TEST output will go HIGH if the sending IED is in test mode.
Data Value Data Valid Comm Valid Test
Incoming data with q=Normal Updated 1 1 0
Incoming data with q=oldData 0 0 1 0
Incoming data with q=Invalid 0 0 1 0
Incoming data with q=test 0 0 1 1
Incoming data with q=test+oldData 0 0 1 1
Receiver in block 0 0 1 0
Receiver in block and
communication error
0 0 0 0
Table continues on next page
Section 18 1MRK 505 394-UEN A
Station communication
648 Line differential protection RED650 2.2 IEC
Technical manual
