14.12.4 Signals
PID-6938-INPUTSIGNALS v1
Table 320: IB16 Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
INP INTEGER 0 Integer Input
PID-6938-OUTPUTSIGNALS v1
Table 321: IB16 Output signals
Name Type Description
OUT1 BOOLEAN Output 1
OUT2 BOOLEAN Output 2
OUT3 BOOLEAN Output 3
OUT4 BOOLEAN Output 4
OUT5 BOOLEAN Output 5
OUT6 BOOLEAN Output 6
OUT7 BOOLEAN Output 7
OUT8 BOOLEAN Output 8
OUT9 BOOLEAN Output 9
OUT10 BOOLEAN Output 10
OUT11 BOOLEAN Output 11
OUT12 BOOLEAN Output 12
OUT13 BOOLEAN Output 13
OUT14 BOOLEAN Output 14
OUT15 BOOLEAN Output 15
OUT16 BOOLEAN Output 16
14.12.5 Setting parameters
ABBD8E242451 v3
The function does not have any parameters available in local HMI or Protection
and Control IED Manager (PCM600)
14.12.6 Operation principle
SEMOD158385-4 v4
With integer 15 on the input INP the OUT1 = OUT2 = OUT3= OUT4 =1 and the
remaining OUTx = 0 for (5≤x≤16).
OUTx represents a value when activated. The value of each of the OUTx is in
accordance with the table IB16_1. When not activated the OUTx has the value 0.
