Cause
number
Name Description Supported
-25 Blocked-for-close-
cmd
Blocked for Close Command X
-30 Long-operation-time Operation time too long X
-31 Switch-not-start-
moving
Switch did not start moving X
-32 Persistent-
intermediate-state
Switch stopped in intermediate state X
-33 Switch-returned-to-
init-pos
Switch returned to the initial position X
-34 Switch-in-bad-state Switch is in a bad position state X
-35 Not-expected-final-
position
Switch did not reach the expected final position X
Table 184: Translation of cause values for IEC 61850 edition 2 and edition 1
Internal Cause
Number
AddCause in IEC 61850-8-1 Name
Ed 2 Ed 1
0 25 0 None
1 1 1 Not-supported
2 2 2 Blocked-by-switching-hierarchy
3 3 3 Select-failed
4 4 4 Invalid-position
5 5 5 Position-reached
6 6 6 Parameter-change-in-execution
7 7 7 Step-limit
8 8 8 Blocked-by-Mode
9 9 9 Blocked-by-process
10 10 10 Blocked-by-interlocking
11 11 11 Blocked-by-synchrocheck
12 12 12 Command-already-in-execution
13 13 13 Blocked-by-health
14 14 14 1-of-n-control
15 15 1 Abortion-by-cancel
16 16 16 Time-limit-over
17 17 17 Abortion-by-trip
18 18 18 Object-not-selected
19 19 3 Object-already-selected
20 20 3 No-access-authority
24 24 -23 Blocked-by-command
26 26 6 Inconsistent-parameters
27 27 12 Locked-by-other-client
Table continues on next page
Section 12 1MRK 505 394-UEN A
Control
352 Line differential protection RED650 2.2 IEC
Technical manual
