Name Values (Range) Unit Step Default Description
EventMask7 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 7
EventMask8 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 8
EventMask9 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 9
EventMask10 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 10
EventMask11 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 11
EventMask12 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 12
EventMask13 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 13
EventMask14 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 14
EventMask15 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 15
EventMask16 NoEvents
OnSet
OnReset
OnChange
AutoDetect
-
- AutoDetect Reporting criteria for input 16
MinRepIntVal1 0 - 3600 s 1 2 Minimum reporting interval input 1
MinRepIntVal2 0 - 3600 s 1 2 Minimum reporting interval input 2
MinRepIntVal3 0 - 3600 s 1 2 Minimum reporting interval input 3
MinRepIntVal4 0 - 3600 s 1 2 Minimum reporting interval input 4
MinRepIntVal5 0 - 3600 s 1 2 Minimum reporting interval input 5
Table continues on next page
