Name Values (Range) Unit Step Default Description
InfNo14 0 - 255 - 1 0 Information number for binary channel
14 (IEC -60870-5-103)
FunType15 0 - 255 - 1 0 Function type for binary channel 15 (IEC
-60870-5-103)
InfNo15 0 - 255 - 1 0 Information number for binary channel
15 (IEC -60870-5-103)
FunType16 0 - 255 - 1 0 Function type for binary channel 16 (IEC
-60870-5-103)
InfNo16 0 - 255 - 1 0 Information number for binary channel
16 (IEC -60870-5-103)
Table 403: B1RBDR Non group settings (advanced)
Name Values (Range) Unit Step Default Description
TrigLevel01 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 1
IndicationMa01 Hide
Show
- - Show Indication mask for binary channel 1
TrigLevel02 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 2
IndicationMa02 Hide
Show
- - Show Indication mask for binary channel 2
TrigLevel03 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 3
IndicationMa03 Hide
Show
- - Show Indication mask for binary channel 3
TrigLevel04 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 4
IndicationMa04 Hide
Show
- - Show Indication mask for binary channel 4
TrigLevel05 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 5
IndicationMa05 Hide
Show
- - Show Indication mask for binary channel 5
TrigLevel06 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 6
IndicationMa06 Hide
Show
- - Show Indication mask for binary channel 6
TrigLevel07 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 7
IndicationMa07 Hide
Show
- - Show Indication mask for binary channel 7
TrigLevel08 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 8
IndicationMa08 Hide
Show
- - Show Indication mask for binary channel 8
TrigLevel09 Trig on 0
Trig on 1
- - Trig on 1 Trigger on positive (1) or negative (0)
slope for binary input 9
Table continues on next page
