en07000104-3.vsd
50
55
[ms]
[mA]
IEC07000104 V3 EN-US
Figure 378: Approximate binary input inrush current for the standard version of
BIM.
en07000105-1.vsd
50
5.5
[ms]
[mA]
IEC07000105 V2 EN-US
Figure 379: Approximate binary input inrush current for the BIM version with
enhanced pulse counting capabilities.
1MRK 505 394-UEN A Section 22
IED hardware
Line differential protection RED650 2.2 IEC 821
Technical manual
