Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
159
202 / 203
Zero position optical sensor of rotation still
active after exiting from zero sensor
9.2.3.1
204
Unexpected activation of rotation optical sensor
9.2.3.2
205
Timeout on rotation
9.2.3.1
Y translation motor
Code
Error description
Reference
paragraph
240
Zero position micro Y always active
9.2.3.3
241
Zero position micro Y never active
9.2.3.3
243
Timeout on Y axes
9.2.3.3
Chin rest
Code
Error description
Reference
paragraph
265
Zero position micro chin rest always active
9.2.3.4
266
Zero position micro chin rest never active
9.2.3.4
268
Chin rest timeout
9.2.3.4
Hardware key board (U.I.C.)
Code
Error description
Reference
paragraph
270 / 271
Hardware key fault
9.2.3.5
X-ray Controls
Code
Error description
Reference
paragraph
360
RX button pressed on start-up or before exam
9.2.4.1
362
RX button released during emission
9.2.4.2
Sensor ready
Code
Error description
Reference
paragraph
370
Sensor ready lost during exposure
9.2.4.3
371
Sensor not ready
9.2.4.4
CCU Board
Code
Error description
Reference
paragraph
