Service Manual – Troubleshooting
SERVICE MANUAL • X-MIND prime 3D • (19) • 11/2019 • NXMPEN080A
160
600/601/
605
CCU malfunctioning errors
9.2.6.1
602÷ 604
Ceph operative errors
9.2.6.1
606
Nasion calibration error
Currently not
implemented
611
Internal CCU error
9.2.6.1
623 / 624
CCU eeprom errors
9.2.6.7
630 ÷ 635
Sensor movement errors
9.2.6.8
640 ÷ 645
Secondary collimator movement errors
9.2.6.9
650 ÷ 661
4 blade collimator movement errors
9.2.6.10
670 / 671
Can Bus errors
9.2.6.11
680
Ceph exam aborted
Restart the exam
Generator Board
Code
Error description
Reference
paragraph
750
Generator board initialization error
9.2.7.1
751
Alarm “overvoltage kV”
9.2.7.2
752
Alarm “overload on filament” on Generator board
9.2.7.3
753
Alarm “overload anodic current”
9.2.7.4
754
Alarm “filament not OK”
9.2.7.5
755
Alarm “backup timer”
9.2.7.6
756
Alarm “PFC not OK”
9.2.7.7
757
Alarm “Brown OUT”
9.2.7.8
758
Alarm “NO X-ray”
9.2.7.9
759
Alarm “unexpected emission”
9.2.7.10
760
Alarm “NO RX button command”
9.2.7.11
761
Alarm “NO X-ray emission”
9.2.7.9
762
Bad unit status: emission flag detected
unexpectedly
9.2.7.12
763
kV analog feedback out of range
9.2.7.13
Generator Board
Code
Error description
Reference
paragraph
