Effect mode
146
NOISE GATE
This is a monaural effect that silences the signal if it drops below a specified level (thresh-
old). It is convenient to use this to cut any noise that may be heard while you are not play-
ing.
PAN>AUTOPAN
This is an autopan effect that automatically moves the sound between left and right. It
can be used to give the sound a sense of movement and depth.
PAN>TRIGGERPAN
This is an autopan effect that starts when the signal of the specified effect bus A–D
exceeds a given level. You can also use the [F3] (MANUAL) key to start it manually.
Parameter Range Function
Threshold
–60dB–0dB Adjusts the threshold of the noise gate.
Key
SEND
A–SEND
Specifies the signal source (send A–D) that will drive the noise
gate.
Output
–20dB–+20dB Adjusts the output level of the effect sound.
Attack
0–127 Adjusts the attack of the effect.
Release
0–127 Adjusts the release of the effect.
Hold
0–127 Adjusts the hold time of the effect.
Wet/Dry
100/0–0/100
Adjusts the balance of the effect sound and dry sound. (With a
setting of 100/0, only the effect sound is output.)
Effect
ON/OFF Switches the effect on/off.
Parameter Range Function
Rate
0.1Hz–10.0Hz Adjusts the speed of panning.
Mode
Pan/L>R/R>L
Pan
...... Conventional autopan.
L>R
..... Simulates a sound that rotates counter-clockwise in
front of the listener.
R>L
..... Simulates a sound that rotates clockwise in front of the
listener.
Width
0–127 Adjusts the stereo width.
Rate
0.1Hz–10.0Hz Adjusts the width of panning.
Wet/Dry
100/0–0/100
Adjusts the balance of the effect sound and dry sound. (With a
setting of 100/0, only the effect sound is output.)
Effect
ON/OFF Switches the effect on/off.
Parameter Range Function
Rate
0.1Hz–10.0Hz Adjusts the speed of panning.
Mode
Pan/L>R/R>L
Selects the autopan effect. The effects are the same as in AUTO
PAN.
Trigger
SEND A–SEND D Selects the signal source that will start autopan.
MANUAL Use the [F3] key to start autopan.
Threshold –60dB–0dB Adjusts the signal level that will start autopan.
Width 0–127 Adjusts the width of panning.
Wet/Dry 100/0–0/100
Adjusts the balance of the effect sound and dry sound. (With a
setting of 100/0, only the effect sound is output.)
Effect ON/OFF Switches the effect on/off.
Pan
L R
L R
LR
LR
LR
