DECT 4070 IO/EO BASE STATIONS TERMINALS
Ed. 042/2 Réf. 3EH 21000 BSAA
Local power supply
It is possible to connect a local power supply (230V/42V – 150 mA adapter) to an accessible socket
on the lower part of the 4070 IO/EO base.
The local power supply is used in the following cases:
- main power supply not authorized on the line's wires (depending on specific installation require-
ments)
- to increase the cable length between the interface and the station
- reduction in the system's electrical consumption.
When the external power supply is connected, the base passes automatically to local power supply mo-
de. In the event of a power cut, the base is not supplied.
States of the correct operation LED
State of the base station State of the LED
No power supply (local or remote) or fault on base Off
Fault after auto-test, base not operational On
Auto-test OK, base station operational. Normal operation for
a base with 2 links.
1s on / 1 s off
Auto-test OK, base station operational. Normal operation for
a base with one Master link only.
1s on / 200 ms off
Master link not connected, local power supply or slave link
connected.
50 ms on / 50 ms off
