CAPACITIES AND LIMITSPRODUCT PRESENTATION
Ed. 04 1/10Réf. 3EH 21000 BSAA
File
CAPACITIES AND LIMITS
The following table gives the capacities provided by the various Alcatel OmniPCX Office solutions.
S / e-S M / e-M L / e-L XL / e-XL Maximum
limits
System
Type of module Rack 1 Rack 2 Rack 3 Rack 3 +
extension
Rack 3
3 modules,
all combina-
tions possi-
ble
Total number of slots (with CPU
and MEX boards
3691827
Available slots 2 5 8 16 24
Total number of CPU/CPUe
boards
1
Total number of UAI16 boards 1 3 4 8 12
Total number of SLI16 boards 0 2 5 10 12
Total number of UAI16 + MIX
boards
254 812
Co-processing CPU (CoCPU)
including 1 CoCPU@ maxi-
mum per system
122 5 6
IP channels 16 32 32 80 88
VOIP daughterboards 1 2 2 5 6
Hard disk 1 2
Hard disk capacity 6 Gbytes minimum
Communication ports
Users' ports (Reflexes + Z) 28 56 96 192 200
Multi-Reflexes 4099 6 6 6 12 18
Lanswitch boards 1 LanX16 1 LanX16
+ 1 LanX8
2 LanX16 4 LanX16 6 LanX16
Available Ethernet ports (*) 14 20 28 56 84
Analog trunk lines (**) 4 16 24 48 72

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
