9
UAI BOARDHARDWARE
Ed. 04 1/2Réf. 3EH 21000 BSAA
File
UAI BOARD
The UAI board allows the connection of Alcatel Reflexes stations (UA). 3 board versions are available:
- UAI4: 4 UA interfaces
- UAI8: 8 UA interfaces
- UAI16: 16 UA interfaces
OBC
Plug-in to BACKX board
CATS
CATS
CATS
CATS
UA interfaces 9 to 12
UA interfaces 13 to 16
UA interfaces 1 to 4
UA interfaces 5 to 8
