Alcatel OmniPCX Office Technical Documentation

MIX BOARD HARDWARE
Ed. 042/2 Réf. 3EH 21000 BSAA
OUTPUT PORTS (BOARD STIFFENER)
CONNECTING AN ANALOG STATION (Z)
Follow the rules in the "SLI board" section.
CONNECTING AN ALCATEL REFLEXES STATION
Follow the rules in the "UAI board" section.
CONNECTING A T0 BASIC ACCESS
Follow the rules in the "BRA board" section.
RJ45 pin 12345678
Z outputs ZA ZB
UA outputs L1 L2
T0 outputs TX+ RX+ RX- TX-
12 34 12 34
1
2
3
4
5
6
7
8
MIXED
DIGITAL INTERFACES
ISDN T0 ANALOG INTERFACES
MIX4/8/4
12 34 56 78
123
4
12 3 4
MIXED
DIGITAL INTERFACES
ISDN T0 ANALOG INTERFACES
MIX4/4/8
ANALOG INTERFACES
12345678
Female RJ45, front

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
