Alcatel OmniPCX Office - LANX BOARD

11
LANX BOARDHARDWARE
Ed. 04 1/4Réf. 3EH 21000 BSAA
File
LANX BOARD
The LanX board (Ethernet LAN Switch) serves to connect Ethernet terminals (IEEE 802.3 compatible). 2
board versions are available:
- LanX8: eight 10/100 BT Ethernet ports (ports 1 to 7: MDI-X/crossover; Uplink: MDI-II/straight)
- LanX16: sixteen 10/100 BT Ethernet ports (ports 1 to 15: MDI-X/crossover; Uplink: MDI-II/straight)
Plug-in to BACKX board
OBC
Converter
KS8998
KS8998
