SLI BOARD HARDWARE
Ed. 042/2 Réf. 3EH 21000 BSAA
OUTPUT PORTS (BOARD STIFFENER)
CONNECTING AN ANALOG Z STATION
The sets are equipped with a cable and self-acting switch for connection to a wall socket. Each set is
connected up with a pair of 0.5 or 0.6-mm wires (the maximum distance with 0.5-mm cabling is 1.3
km).
RJ45 pin 12345678
Outputs ZA ZB
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
ANALOG INTERFACES
SLI16
12345678
Female RJ45, front
ZB
ZA
1
3
5
2
4
6
Distribution panel
ANALOG INTERFACES
SLI16
