Alcatel OmniPCX Office Technical Documentation

20
ALTERNATIVE CLIP AND COLP
NUMBERS
CALL SERVER : TELEPHONE FEATURES
Ed. 04 1/2Réf. 3EH 21000 BSAA
File
ALTERNATIVE CLIP AND COLP
NUMBERS
CLIP and COLP are services that depend upon the public network (France: COLP is not provided)
These functions are provided by Alcatel OmniPCX Office systems connected to a public ISDN network
(T0/T2 access).
Definitions
CLIP (Calling Line Identification Presentation): identification number sent by the caller when making
an outgoing ISDN call.
COLP (Connected Line Presentation): identification number returned by the called party to the caller.
ALTERNATIVE SYSTEM CLIP
Description
This function is used to configure the calling number (CLIP) sent to correspondents on outgoing ISDN
calls. For example, it enables a company with several sites always to send the same number to external
called parties.
On an outgoing external call, the number transmitted is:
- the installation number completed by the DDI number of the caller (or the Operator Group num-
ber), if the "Alternative CLIP number" is not configured.
- the "Alternative CLIP number", if configured.
Without "Alternative CLIP number" With "Alternative CLIP number"
Installation number: 9125-5833
Alternative system CLIP : 0800111000
Public Network
DDI number: 111
T0/T2
Calling line number
(CLIP): 0800111000
Installation number: 9125-5833
Alternative system CLIP : none
Public Network
DDI number: 111
91255833111
T0/T2
Calling line number(CLIP)
