2
MULTI-REFLEXES 4099 HUBTERMINALS
Ed. 04 1/2Réf. 3EH 21000 BSAA
File
MULTI-REFLEXES 4099 HUB
Multi-Reflexes option 4099 connects up 3 Alcatel Reflexes terminals using just one UA system link; this
option makes it easier to install additional Reflexes terminals.
Option 4099 separates out the 3 B-channels of the UA interface into 3 terminal interfaces.
UA/PBX
UA/Reflexes 3UA/Reflexes 2
UA/Reflexes 1
UA
LED
3
2
UA link
Station interfaces
Reflexes 1
Option 4099
Reflexes
2
Reflexes 3
