Alcatel OmniPCX Office Technical Documentation

2
INSTALLATION - CONFIGURATIONCALL SERVER : VOICE ON IP
Ed. 04 1/20Réf. 3EH 21000 BSAA
File
INSTALLATION - CONFIGURATION
INSTALLATION GUIDE
Preliminary
A few precautions must be taken when inserting a machine into a local network to ensure the lasting
compatibility and quality of the network.
The starting point for the integration and configuring of the PBX on a LAN is the knowledge of the
network structure, its characteristics and the equipment. After that it is necessary to collect the signifi-
cant parameters and characteristics of the LAN.
Below is a non-exhaustive list of the parameters to be collected:
VoIP CoCPU board
- Hostname: DNS name or alias of the board.
- IP Address: IP address of the board.
- IP Subnet Mask: subnet mask of the LAN.
General
- Number of IP trunk DSP channels: number of channels associated with remote H.323 gateway ac-
cess.
- Number of IP subscriber DSP channels: number of channels associated with the IP Telephony ser-
vice.
- Implicit router address: default address of router.
- Quality of service: type of quality of service to be implemented according to the LAN equipment.
Gatekeeper
- Gatekeeper integrated into the PBX: use of an integrated gatekeeper or not.
- Identification of gatekeeper: IP address of external gatekeeper.
DHCP
- Activate integrated DHCP server: use of the integrated DHCP server or not.
- Dynamic Range: dynamic IP address range for IP telephony (IP Enabler).

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
