Alcatel OmniPCX Office Technical Documentation

3
COMPLIANCE WITH STANDARDSPRODUCT PRESENTATION
Ed. 04 1/2Réf. 3EH 21000 BSAA
File
COMPLIANCE WITH STANDARDS
SAFETY DECLARATION
Compliance with IEC 60950 3rd ed. standards
SELV: Safety Extra Low Voltage
TNV-3: Telecommunication Network Voltage
To maintain safety levels, it is essential to connect up circuits of the same nature and to ensure that all
means of connection comply with the constraints laid down for each circuit type.
Interface classifica-
tion
Interface location
TNV-3 - Z interface (SLI board)
- Z interface for Alcatel Reflexes station (AP board)
- Analog trunk line interface (ATA board)
SELV - Alcatel Reflexes station interface (UAI board or Multi-Reflexes option 4099)
- 4070 IO/EO base station interface (UAI board)
- T0 interface (BRA board)
- T2/T1 interface (PRA board)
- S0 interface (S0 board)
- Please-wait or background music interface (CPU/CPUe board)
- Alarm interface (CPU/CPUe board)
- General bell interface (CPU/CPUe board)
- Doorphone interface (CPU/CPUe board)
- Loudspeaker interface (CPU/CPUe board)
- V24 interface (CPU/CPUe board)
- CTI interface for Alcatel Reflexes station (CTI or V24/CTI board)
- 10/100 base T Ethernet interface (CPU/CPUe or CoCPU/CoCPU@ board)
- 4070 IO/EO base station (inputs-outputs)
- 4097 CBL UA/DECT adapter

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
