Alcatel OmniPCX Office Technical Documentation

1
INSTALLATION PROCEDURESPM5 : SYSTEM CONFIGURATION
Ed. 04 1/10Réf. 3EH 21000 BSAA
File
INSTALLATION PROCEDURES
PM5 is the unified administration and configuration tool for Alcatel OmniPCX Office; running on a PC,
it can be used to program the system's voice functionality, voice mail, the network, Internet access,
downloading… even the printing of mailing labels.
MINIMAL PC CONFIGURATION
- Pentium 166 MHz processor.
- RAM: 32 MB for Windows 95, 98 and 2000; 64 MB for Windows NT.
-Hard disk.
- Screen: 800 x 600 pixels
-1 mouse.
- 1 serial port (connection to Alcatel OmniPCX Office for data transfer)
- 1 Ethernet board (IP mode).
- Operating system: Windows 95, 98, 2000 or NT4, pack 5 minimum.
- 64K PPP-compatible ISDN or V34 modem for remote access.
INSTALLING THE PM5 SOFTWARE
The PM5 software is installed from a CD-ROM.
The application is installed by making selections from the options proposed in the various windows.
When installation is completed, you access the application by double-clicking on the new icon created
on the Windows desktop or:
- Select Start then Program then Alcatel OmniPCX Office then PM5.
-The window Welcome to PM5 appears.
PM5 REMOTE ACCESS
Remote access with PM5 makes it possible to configure or download to an Alcatel Omni PCX Office
system.This access can be managed with:
- an ISDN modem able to use ISDN PPP (point to point) protocol at 64 K.
- a V34 analog modem in Hayes protocol at 33600 bds.
These two modems are integrated on Alcatel OmniPCX Office.
It is implied that software PM5 will have to be installed before on the PC using remote maintenance.

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
