CAPACITIES AND LIMITS PRODUCT PRESENTATION
Ed. 048/10 Réf. 3EH 21000 BSAA
POWER SUPPLY LIMITS
The following tables give the details power consumption of the different items (boards and terminals)
and the limit not to be exceeded for each model (all values are in W unit).
The maximum budget at the charger level is also indicaded for each model and you have just to add
the values for all items presents in the system. The configuration will be in the power supply limits if the
total obtained is less or equal to the maximum budget allowed to the type of rack used :
- maximum budget for Rack 1 = 34 W
- maximum budget for Rack 2 = 57 W
- maximum budget for Rack 3 = 85 W
Boards and terminals Rack 1 Rack 2 Rack 3
CPU boards
CPU/CPUe 5,16 6,40
CoCPU/CoCPU@ 5,73 7,10
MEX 1,32 1,64
Daughter boards
XMEM 0,10 0,12
VOIP 16 channels 1,74 2,16
VOIP 8 channels 1,01 1,25
VOIP 4 channels 0,65 0,81
HSL 0,30 0,37
WAN 0,73 0,91
Hard Disk 2,33 2,89
SLANX 1,62 2,01
AFU 0,55 0,68
Trunk boards
BRA 8 0,97
BRA 4 0,56
BRA 2 0,33
Metering 0,06
PRA - T2/T1 0,33
ATB 4 1,42
ATB 2 0,78
