PRINCIPLES OF ARS MECHANISMSCALL SERVER : PRIVATE NETWORKS
Ed. 04 3/18Réf. 3EH 21000 BSAA
USE OF THE VARIOUS TABLES
- The various parameters required for ARS mechanisms are configured using MMC-PM5 (Expert
View) only
- Structure of the main tables:
- Dimensions:
Max. number of prefixes (= number of lines in each of the 2 tables): 120
Max. number of entries in the trunk group lists (= number of lines in each of the 2 tables): 120
Max. number of ranges: 120.
- by MMC-PM5 (Expert View), select: Numbering -> Automatic Routing Selection. -> then con-
figure the following tables:
•ARS table
• Trunk groups list
• Hours table
• Day table
• Providers / Destinations
• Authorization codes
•Tone/Pause
- ARS miscellaneous
Network Prefix Ranges Called/HH
User
Substitute
TrGrp
list
ARS ta
bl
e
Trunk group list
Pub 885040
Het
51
1
TrGrp list
Index
TrGr p No.
Char
Ton e/ Pa us e
Access digits
Authorization
codes
Client code table
Tone/Pau se ta bl e
1 3 503 T 08
131
02
Fields and tables for multi-operator use
0-3 ; 6-7
Optional
fields
comment
Provider/
Destination
FT_NATIONAL
